Page 22 - Olipes Offhighway
P. 22
Air
Compressors
TYPE OF
FLOW SYN CP
BRANDS COMPRESSOR Synthetic PAO FLOW CP
Mineral
ABAC Screw 32 (>15ºC: ISO 46) Optional
Screw 32/46/68 Optional
ATLAS COPCO
Piston 68 Optional 68
Screw 32/46/68 Optional
CHICAGO NEUMATIC
Piston 68 Optional 68
Screw 32/46/68 Optional
COMPAIR-HOLMAN Hydrovane 100/150
Piston 100/150
FULLER (DAVEY) Rotary Vane 100/150
Screw 46/68 Optional
GARDNER DENVER
Piston 100
Type 30/40 (Piston) 100
SS, TS... (Piston) 100
INGERSOLL-RAND Pacair 46 Optional 46
SSR (Screw) Manufacturer recommendation: SSR Ultra Coolant ® . Contact Olipes SAT
Centac (Centrifugal) 32 Optional 32
PORTABLES VHP, XHP (Screw) 68 Optional 68
Screw 46/68 Optional
JOY MANUFACTURING
Piston 100
Screw 32/46/68 Optional
KAESER
Piston 100/150
Screw 46/68 Optional
LeROI Rotary Vane 100 (Contact SAT)
Piston 100/150
Screw 46/68 Optional
QUINCY
Piston 68 (Contact SAT)
Screw 46 Optional 46
SCHRAMM
Piston 100/150
SULLAIR Screw 46 Optional 46
Screw 46/68 Optional
WORTHINGTON
Piston 100/150
* In red the viscosity ISO VG recommended by the manufacturer. In black alternative viscosities according to the working conditions.
COMPRESSOR OILS COMPATIBILITY DEPENDING ON THEIR NATURE
Base Oils Mineral PAO (Poly-Alpha-Olefin) Ester Polyglycol
Mineral M M M NM
PAO (Poly-Alpha-Olefin) M M M NM
Ester M M M M
Polyglycol NM NM M M
M: Miscibles NM: Unmiscibles
This is merely an orientative guide for lubricants (mineral and synthetic) recommended by the main
air compressor manufacturers. For specific recommendations about each compressor brand and
model, consult the manufacturer’s manual or go to the OLIPES Technical Assistance Service (SAT). Do
not mix lubricants of different kinds, even when they are all synthetic, as they may be incompatible.
The recommended viscosity shall depend on the working conditions of the compressor.
